What a TPS sensor does

The throttle position sensor tells your engine computer how far the throttle is open. When it fails you get hesitation, surging, a bad idle or limp mode. The short version, with the two drawings that explain nearly every TPS fault.

The throttle position sensor sits on the throttle body, on the end of the throttle shaft. It gets a 5 volt reference and a ground from the engine computer and returns a signal voltage that rises as the throttle opens. Code references cite roughly 0.5 volts at idle and 4.5 volts at full throttle as a typical pattern, but the exact numbers for your engine are in its service manual (OBD-Codes.com).

Classic sensors are a potentiometer: a wiper sliding along a resistive track. When the track wears, the signal drops out at one spot, and the engine stumbles there. Some sensors read a magnet with no contact at all (SMP listing).

On an electronic throttle, there is no cable. A motor opens the throttle, and two position signals inside the throttle body are compared constantly. When they disagree you get P2135 and usually reduced power.

5V REFSIGNALGROUND TPS ENGINECOMPUTER WIRE COLORS AND PIN ORDER VARY BY VEHICLE
Fig. 01The three-wire circuit.
5V0VCLOSEDWIDE OPENSMOOTH SWEEP
Fig. 02A healthy signal: a smooth climb from closed to wide open.

TPS symptom checker

Tick what the vehicle is doing and any codes. You get the likely causes, ranked, with the next check for each. It is a guide, not a diagnosis.

01 What is the vehicle doing?
02 Any stored codes?
03 Throttle type

Look at the throttle body: a cable from the gas pedal means cable; no cable means electronic.

Likely causes

Pick at least one symptom or code to see likely causes.

TPS trouble codes

Six generic OBD-II codes cover most throttle position faults. The last word of the title tells you where to look first.

Generic OBD-II throttle position codes. Titles from OBD-Codes.com; your maker may word them differently.

CodeGeneric titleIn plain EnglishGuide
P0120Throttle Position Sensor/Switch A Circuit MalfunctionThe signal is outside the range the computer expects.P0120 guide
P0121Throttle Position Sensor/Switch A Circuit Range/PerformanceThe signal does not match what the engine is doing (RPM, airflow).P0121 guide
P0122Throttle Position Sensor/Switch A Circuit Low InputThe signal voltage is too low, often an open or a short to ground.P0122 guide
P0123Throttle Position Sensor/Switch A Circuit High InputThe signal voltage is too high, often a lost ground or a short to voltage.P0123 guide
P0124Throttle Position Sensor/Switch A Circuit IntermittentThe signal drops in and out: wiring, a connector or a worn track.Codes hub
P2135Throttle/Pedal Position Sensor/Switch A/B Voltage CorrelationThe two sensors in an electronic throttle body disagree.P2135 guide

Open the codes hub for P0124 and the first checks for every code.

Separate sensor, or built into the throttle body?

This one question decides what you buy and what it costs.

TPS

Cable throttle

A cable runs from the pedal to the throttle body. The TPS is usually a separate part on two screws. Some older ones are adjustable.

Replace a TPS

MOTOR + TPS

Electronic (drive by wire)

No cable; a motor moves the throttle. The sensors are usually inside the throttle body, so the fix is often a throttle body.

TPS vs throttle body

Buying a TPS sensor

Fitment beats brand. Match the part to your VIN or the number on your old sensor, then choose between OEM and aftermarket.

Who makes replacement throttle position sensors. No rankings: fitment matters more than the logo.

BrandWhat it isSourceShop
Standard Motor ProductsLarge aftermarket engine management maker. Some of its sensors are built to match OE output rather than being adjustable, and some read a magnet on the shaft with no contact.Maker or listing pageSearch Amazon
DelphiFormer GM parts arm with an aftermarket sensor line that includes throttle position sensors.Maker or listing pageSearch Amazon
BoschSays its aftermarket TPS is tested to the same standards as its original equipment parts (maker claim).Maker or listing pageSearch Amazon
Walker ProductsSensor and fuel system maker; describes its TPS as built for OE fit, form and function (maker claim).Maker or listing pageSearch Amazon
DormanBroad replacement parts catalog with TPS for GM, Dodge, BMW and many more.Maker or listing pageSearch Amazon
Hitachi (Astemo)The former Hitachi Automotive, an OE supplier that sells TPS in the aftermarket.Maker or listing pageSearch Amazon
OEM (dealer) partsACDelco for GM, Motorcraft for Ford, Mopar for Jeep, plus Toyota and Honda genuine parts. Usually the priciest, always the exact match.Dealer parts counterSearch Amazon
Shop throttle position sensors Multimeters for testing Scan tools

We have not bench-tested these brands. Notes come from maker and distributor pages; maker claims are labeled. How we choose.

Questions people ask

What does a TPS sensor do?

The throttle position sensor tells the engine computer how far the throttle is open. The computer uses it for fueling, idle control, and on many automatics, shift timing. Most send a voltage on a signal wire that rises as the throttle opens, from a 5 volt reference.

What are the symptoms of a bad TPS sensor?

Hesitation or stumbling when you press the gas, surging, a rough, low or racing idle, stalling, odd automatic shifts, reduced power on electronic throttles, and a check engine light with codes such as P0120 to P0124 or P2135.

Can I replace a TPS sensor myself?

On a cable throttle with a separate sensor, usually yes: a plug and two screws, then a check of the closed-throttle reading and any relearn your vehicle needs. On electronic throttles the sensors are usually inside the throttle body, which is a bigger job.

How much does it cost to replace a TPS sensor?

Published estimates for a separate sensor run roughly $120 to $355 at a shop, mostly labor. A sensor built into an electronic throttle body can mean $300 to $800 or more. See the cost guide for sources.

Is a TPS sensor the same as a tire pressure sensor?

No. TPS is the throttle position sensor on the engine. The tire pressure sensor is TPMS, fitted in each wheel. If the warning light on your dash is a tire symbol, you need a TPMS fix, not a TPS.
